Description
Crown Xavier 1.5kW Off-Grid Solar Inverter (PV-2000) Specifications |
|
|---|---|
| Category | Specification |
| Model | XAVIER 1.5KW (PV-2000) |
| Rated Power | 1500VA / 1500W |
| Surge Power | 2400VA |
| Input Voltage | 230 VAC |
| Selectable Voltage Range | 90–280V (Home) / 170–280V (PC) |
| Frequency | 50 / 60 Hz (Auto Sensing) |
| Waveform | Pure Sine Wave |
| Transfer Time | 10ms (PC) / 20ms (Home) |
| Battery Voltage | 12 VDC |
| Floating Charge Voltage | 13.5 VDC |
| Overcharge Protection | 16 VDC |
| Solar Charger Type | MPPT |
| Max PV Array Power | 2000W |
| MPPT Range | 30–300 VDC |
| Max PV Open Circuit Voltage | 350 VDC |
| Max Solar Charge Current | 80A |
| Max AC Charge Current | 80A |
| Max Total Charge Current | 80A |
| Efficiency (Peak) | 93% |
| Display | LCD |
| Communication | RS-232 |
| Dimensions (D x W x H) | 90 x 288 x 357 mm |
| Weight | 6.5 kg |
| Humidity | 5% to 95% (Non-condensing) |
| Operating Temperature | -10°C to 50°C |
| Storage Temperature | -15°C to 60°C |
| For technical details visit: Crown Micro Inverters | |
